| WHEEL SIZE 车轮型号 | BOLT HOLES 螺丝孔 | P.C.D(mm) | CBD(mm) | OFFSET | DISK THICKNESS | Tyre Size 配用轮胎 | ||
| HOLES NO. 孔数 | HOLE DIA 孔径 | HOLE TYPE 孔状 | 分布圆直径 | 中心孔直径 | 偏距(mm) | 轮辐厚度(mm) | ||
| 22.5x9.00 | 8 | 32 | SR22 | 275 | 214 | 175 | 12 | 12R22.5 315/80R22.5 |
| 175 | 14 | |||||||
| 22.5x9.00 | 8 | 32 | SR22 | 285 | 221 | 175 | 12 | |
| 175 | 14 | |||||||
| 22.5x9.00 | 8 | 26 | 1x45° | 275 | 220 | 175 | 12 | |
| 175 | 14 | |||||||
| 22.5x9.00 | 8 | 26 | 1x45° | 275 | 214 | 175 | 12 | |
| 175 | 14 | |||||||
| 22.5x9.00 | 10 | 32 | SR22 | 285.75 | 222 | 175 | 12 | |
| 175 | 14 | |||||||
| 22.5x9.00 | 10 | 26 | 1 x45° | 285.75 | 220.5 | 175 | 12 | |
| 175 | 14 | |||||||
| 22.5x9.00 | 10 | 26 | 1 x45° | 335 | 281 | 175 | 12 | |
| 175 | 14 | |||||||
