22.5x7.5
分类：重卡车轮 发布时间：2021-05-24
访问量：436
| WHEEL SIZE | BOLT HOLES | P.C.D | Center Bore Diameter | Disk Thickness | OFF SET | Rec.Tyre |
| HOLES NO. | HOLE DIA | HOLE TYPE | (mm) | （mm） | （mm） | (mm) |
|
|
|
|
|
| 12 |
|
|
| 22.5×7.50 | 8 | 32 | SR22 | 275 | 214 | 14 | 162 | 10R22.5 |
|
|
|
|
|
| 12 |
|
|
| 22.5×7.50 | 8 | 32 | SR22 | 285 | 221 | 14 | 162 | 10R22.5 |
|
|
|
|
|
| 12 |
|
|
| 22.5×7.50 | 8 | 32 | SR22 | 275 | 214 | 14 | 162 | 10R22.5 |
|
|
|
|
|
| 12 |
|
|
| 22.5×7.50 | 8 | 32 | SR22 | 285 | 221 | 14 | 162 | 10R22.5 |
|
|
|
|
|
| 12 |
|
|
| 22.5×7.50 | 8 | 26 | 1×45° | 275 | 221 | 14 | 162 | 10R22.5 |
|
|
|
|
|
| 12 |
|
|
| 22.5×7.50 | 8 | 32 | SR22 | 275 | 214 | 14 | 162 | 10R22.5 |
|
|
|
|
|
| 12 |
|
|
| 22.5×7.50 | 10 | 26 | 1×45° | 285.75 | 220 | 14 | 162 | 10R22.5 |
|
|
|
|
|
| 12 |
|
|
| 22.5×7.50 | 10 | 32 | SR22 | 285.75 | 222 | 14 | 162 | 225/70R22.5 |
|
|
|
|
|
| 12 |
|
|
| 22.5×7.50 | 10 | 26 | 1×45° | 335 | 281 | 14 | 162 | 225/70R22.5 |
|
|
|
|
|
| 12 |
|
|
| 22.5×7.50 | 10 | 26 | 1×45° | 335 | 281 | 14 | 162 | 10R22.5 |
